Features
- Switch Mode Power Supply.
- Modular Construction, Serviceable.
- Surface Mount Technology.
- Battery polarity & deep discharge protection.
- As per IS -15908: 2011 Standard.
- 16 X 2 Dot Matrix LCD Display.
- Standby battery backup with built in charging.
- Fire / Fault status in unambiguous colored LED indication. Switch Mode Power Supply. Tactile Keypad for easy panel operation. System on indication.
- Switch Mode Power Supply.
- Tactile Keypad for easy panel operation.
- System on indication.
- Main, Standby status indication.
- Low Battery visual warning with audible tone.
- Relay output for actuators for Fire and Fault
- Lamp Test facility
Specifications
- Primary Power : 120 ? 220VAC , 50 Hz
- Standby Power : 24V D.C (2 Nos of 12v, 7Ah Sealed Lead acid battery). Quiescent current : 55mA
- Operating Condition : Operating Temperature : 0 ? 49ø C/32-120ø F. Relative Humidity : 93 ñ 2% RH (non- condensing) at 32 ñ2ø C/90 ñ3ø F.
- Charging Circuit : Charging Voltage 28.2V, ñ0.5V. Charging Current 0.5 A (Max.).
- Notification Appliance Circuits Class B wiring : Operating Nominal Voltage : 24VDC. Current for NACs : 0.6 Amp. End-Of-Line Resistor : 4K7, 1/4 watt
- Mechanical Specification Dimensions : (350W X 250H X 100D) Color : Red / White Construction : 18 Gauge (1.22mm) CRCA sheet with powder-coated Finish IP Rating : IP50 Cable Entry : 11x?19mm Knockout in top of the cabinet
- Common Relays Type : Form C No of Relays : 3 Relay Contact Rating : 2Amps @ 30 VDC, 0.5Amps @125VAC. Power Factor : 1
- Initiating Device Circuits (Zone Circuit) All zones are Class B wiring Normal Operating Voltage : 14-21 VDC Alarm Current : 15 ? 30mA Short Circuit Current : 42mA Maximum Loop resistance : 50 ohms Maximum End-Of-Line Resistor : 4.7K, 1/4watt Standby Current : 6.8mA (2.4mA for Detectors)
